Model	R750	Engine Brand	Electric / Laidong 385 / Yanmar 380
Rated Power	8 kW, 72V, 20 Ah / 18.6 kW / 18.4 kW	Cylinder	3
Intake Type	Naturally Aspirated	Emission Standard	Euro 5 / EPA
Rated Load	400 kg	Maximum Load	450 kg
Maximum Digging Force	4.5 kN	Hydraulic System Pressure	25 bar
Fuel Tank Capacity	30 L	Bucket Capacity	0.15 m³
Travel Speed	0 - 6 km/h	Work Cycle Time	9 s
Certification	CE / EPA / EURO5	Overall Height	1550 mm
Width	970 mm	Total Length with Standard Bucket	2700 mm
Total Length without Bucket	2070 mm	Bucket Width	1270 mm
Rear Overhang Length	500 mm	Maximum Operating Height	2920 mm
Height to Bucket Pin	2300 mm	Maximum Bucket Height when Level	2140 mm
Dumping Height	1700 mm	Dumping Reach	150 mm
Track Length on Ground	1300 mm	Ground Clearance	240 mm
Bucket Roll Angle at Ground	27°	Bucket Roll Angle at Maximum Height	114°
Operating Weight	1200 kg	Tire Size	180 x 72 x 45 mm
