| Model | X490 | Engine Brand | Electric / Koop / Rato / Zhongcheng / Briggs & Stratton |
| Rated Power | 8 kW, 72V, 200Ah / 15 kW / 19.2 kW / 9.9 kW | Cylinder | 2 |
| Intake Type | Naturally Aspirated | Emission Standard | Euro 5 / EPA |
| Rated Load | 250 kg | Maximum Load | 350 kg |
| Maximum Digging Force | 4.5 kN | Hydraulic System Pressure | 17-21 bar |
| Fuel Tank Capacity | 10 L | Bucket Capacity | 0.12 m³ |
| Travel Speed | 0 - 6 km/h | Work Cycle Time | 9 s |
| Certification | CE / EPA / EURO5 | Overall Height | 1300 mm |
| Width | 1100 mm | Total Length with Standard Bucket | 2700 mm |
| Total Length without Bucket | 2300 mm | Bucket Width | 1050 mm |
| Rear Overhang Length | 500 mm | Maximum Operating Height | 2530 mm |
| Height to Bucket Pin | 1933 mm | Maximum Bucket Height when Level | 1740 mm |
| Dumping Height | 1400 mm | Dumping Reach | 595 mm |
| Wheelbase | 940 mm | Ground Clearance | 180 mm |
| Bucket Roll Angle at Ground | 27° | Bucket Roll Angle at Maximum Height | 114° |
| Operating Weight | 1200 kg | Tire Size | 23 x 8.5-12 in |
Skid steer
X490 Skid Steer loader
Tackle demanding tasks with the Xinfa X490. Engineered for superior lift height, breakout force & stability to rival the Bobcat S590. Ideal for industrial sites and heavy landscaping. Download the full technical specification sheet.
